Solaris

The ultimate floor rising home cinema

Carson Screens Solaris is a motorized projection screen specifically crafted with ambient light-rejecting innovation. This screen serves as a perfect, unobtrusive alternative for spaces where mounting on walls or ceilings is not feasible. It is also compatible with UST projectors, which are small and compact devices that can project large images from a very short distance, eliminating the need for long cables or ceiling mounts.

Plug, Play & Enjoy

Breeze through setup, no hardwired installation required.

Rises and lowers using the greatest motorized pop-up system

By using “scissor-backed” industry grade cross spring risers allows screen to rises smoothly in a short period of time.

Tab-tensioned format ensure a taut, flat, and ripple-free projection surface.

No drilling required

Just place the screen on a flat surface, sit back and enjoy.

Optimised for UST Projectors.

Optimized for ultra-short-throw projectors. Built using the principle of Fresnel lens, the Carson Solaris screen can show the incident light from the screen to the audience by effectively absorbing ambient light by up to 85%, thus enhancing the brightness and contrast.

Materials

BrightStar Ultra UST 8K

Carson’s BrightStar Ultra UST 8K material incorporates next generation Z-axis optical nano-lens technology to achieve ultra fine-grained 8K+ resolving ability while absorbing 93% of ambient light from the above, left and right sides so that you can enjoy full colour images even when the the curtains are open/lights are on. The material has 0.8 gain to support the latest infinite contrast ratio projectors and uniformly transmits vivid colour in a wide 160 degree arc for the entire audience to enjoy.

Groups of optical lenses on the surface of the screen efficiently focus and redirect the table top light coming from the latest LED and Laser UST projectors to the viewer with minimal loss of brightness (many competitor designs waste 40% to as much as 60% or the precious light energy generated by your projector), while thousands of lines of curved miniature awnings (within which the lenses are embedded) prevent all but 7% of total ambient light from affecting your visual enjoyment. The result is a perceived contrast that is a full magnitude (1000%) better than that produced by a traditional matte white screen.

the curtains are open/lights are on. The material has 0.8 gain and uniformly transmits vivid colour in a wide 160 degree arc for the entire audience to enjoy.

Made from a dark nano particle mix formed on top of a bulk polymer sublayer that prevents sunlight penetration from the rear, Daylight II fully supports HDR10+, Dolby Vision and Rec. 2100, making it an excellent future proof investment for your current and future projectors.

Black backed to prevent sunlight penetration from the rear, BrightStar Ultra fully supports HDR10+, Dolby Vision and Rec. 2100, making it an excellent future proof investment for your current and future projectors.

Carson’s unique textile coatings ensure this highly-elastic fabric material is resistant to creasing, UV, moisture, dust, discolouration and ageing so your screen will continue to perform day-in, day-out for decades to come.

Measurements

FormatSpecViewing areaSize of caseTop borderLeft/ Right borderBottom borderOpen height (Z)
16:970″1150W x 872H1820L x 133H x 123D30305001537
80″1771W x 996H2041L x 133H x 123D30305001662
90″1992W x 1121H2262L x 133H x 123D30305001662
100″2213W x 1245H2484L x 133H x 123D30305001786
110″2435W X 1369H2705L x 133H x 123D30305001910
120″2656W X 1494H2926L x 133H x 123D50505002034

The recorded measurements are for general reference only. Please contact Carson Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification. Although a manufacturer may offer product advice, it may be taken or ignored at the integrator’s discretion. Carson Screens will not be held responsible or be otherwise liable for faulty installations.

Features

High-quality screen in an economical frame construction

Compatible with all projectors including UST

4K/8K Ultra HD, HDR and Active 3D compatible

Up to 7 times higher contrast than conventional front screens

Easy to setup

Projection in brightly lit environments

Remote controller with 12V trigger, allow screen stop at any desired level

ISF-certified screen material

Tab-tensioned design ensures a taut and flat ripple-free projection surface
