Description
Engineered for Precision
Precision in Every Deployment
In crafting the next-generation GMT platform, Carson's experienced engineers researched new aluminium alloys and extrusion methods that significantly increased the stiffness of the bottom bar and main case structure for more repeatable and precise deployments that drop and raise the exact same set positions each and every time you use the screen.
The GMT platform supports screen sizes between 80 and 170 inches diagonal and features floating brackets and accessories to facilitate ceiling, wall and suspension mounting.
Material
Silver UHC Material 8K
Carson's Silver UHC 8K material employs a heterogeneous multilayered architecture constructed via cutting-edge nanotech processes resulting in 50% deeper blacks and a 100% improvement in perceived contrast ratios. The material has 0.8 gain and uniformly transmits vivid colour in a wide 160-degree arc for the entire audience to enjoy.
Made from a dark nanoparticle mix formed on top of a bulk polymer sublayer that prevents sunlight penetration from the rear, Silver UHC 8K fully supports HDR10+, Dolby Vision and Rec. 2100, making it an excellent future-proof investment for your current and future projectors.
Carson's unique chemical engineering ensures this stable material is resistant to creasing, UV, moisture, dust, fire, discolouration and ageing so your screen will continue to perform day-in, day-out for decades to come.
Measurements
| Format | Screen Size | Viewing Area (W × H) | Left / Right / Bottom Border | Top Border | Height | Length | Packing Size |
|---|---|---|---|---|---|---|---|
| 16:9 | 92" | 2037 × 1145 | 40 | 525 | 1857 | 2447 | 2537 × 161 × 174 |
| 16:9 | 100" | 2214 × 1245 | 40 | 425 | 1857 | 2624 | 2714 × 161 × 174 |
| 16:9 | 110" | 2435 × 1369 | 40 | 450 | 2006 | 2846 | 2936 × 161 × 174 |
| 16:9 | 120" | 2656 × 1494 | 40 | 330 | 2011 | 3067 | 3157 × 161 × 174 |
| 16:9 | 130" | 2878 × 1618 | 40 | 200 | 2005 | 3288 | 3378 × 161 × 174 |
| 16:9 | 140" | 3100 × 1743 | 40 | 100 | 2030 | 3510 | 3600 × 161 × 174 |
| 16:9 | 150" | 3321 × 1867 | 40 | 100 | 2154 | 3731 | 3821 × 161 × 174 |
| 16:9 | 160" | 3542 × 1992 | 40 | 100 | 2301 | 3953 | 4103 × 211 × 223 |
| 16:9 | 170" | 3763 × 2116 | 40 | 100 | 2425 | 4174 | 4264 × 211 × 223 |
| 16:9 | 180" | 3984 × 2241 | 40 | 100 | 2550 | 4395 | 4485 × 211 × 223 |
All measurements are recorded in millimetres. The recorded measurements are for general reference only. Please contact Carson Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification. Although a manufacturer may offer product advice, it may be taken or ignored at the integrator's discretion. Carson Screens will not be held responsible or be otherwise liable for faulty installations.
