Description
Engineered for Precision
Consistent, Precise Deployment.
In crafting the next-generation GMT platform, Carson’s experienced engineers researched new aluminium alloys and extrusion methods that significantly increased the stiffness of the bottom bar and main case structure for more repeatable and precise deployments that drop and raise to the exact same set positions each and every time you use the screen.
The GMT platform supports screen sizes between 80 and 170 inches diagonal and features floating brackets and accessories to facilitate ceiling, wall and suspension mounting.
Material
Alpha Matt II HDR 8K
Carson’s Alpha Matt IIG HDR 8K material incorporates next-generation Z-axis glass reinforcement technology to achieve ultra-fine-grained 8K+ resolving ability while strengthening the substrate against creasing from repeated rolling inside the screen canister. The material has 1.1 gain and uniformly transmits vivid colour in a wide 140-degree arc for the entire audience to enjoy.
Made from a special synthetic polymer mix formed on top of a black bulk sublayer that prevents sunlight penetration from the rear, Alpha Matt II fully supports HDR10+, Dolby Vision and Rec. 2100, making it an excellent future-proof investment for your current and future projectors.
Carson’s unique chemical engineering ensures this highly elastic and foldable material is resistant to creasing, UV, moisture, dust, fire, discolouration and ageing so your screen will continue to perform day in, day out for decades to come.
Measurements
| Format | Screen Size | Viewing Area (mm) | Left / Right / Bottom Border (mm) | Top Border (mm) | Height (mm) | Length (mm) | Packing Size (mm) |
|---|---|---|---|---|---|---|---|
| 16:9 | 92" | 2037 × 1145 | 40 | 525 | 1820 | 2267 | 2357 × 161 × 174 |
| 16:9 | 100" | 2214 × 1245 | 40 | 424 | 1820 | 2444 | 2534 × 161 × 174 |
| 16:9 | 110" | 2435 × 1369 | 40 | 450 | 1969 | 2666 | 2756 × 161 × 174 |
| 16:9 | 120" | 2656 × 1494 | 40 | 330 | 1974 | 2887 | 2977 × 161 × 174 |
| 16:9 | 130" | 2878 × 1619 | 40 | 200 | 1968 | 3108 | 3198 × 161 × 174 |
| 16:9 | 140" | 3099 × 1743 | 40 | 100 | 1993 | 3330 | 3420 × 161 × 174 |
| 16:9 | 150" | 3321 × 1867 | 40 | 100 | 2117 | 3551 | 3641 × 161 × 174 |
| 16:9 | 160" | 3542 × 1992 | 40 | 100 | 2301 | 3773 | 3863 × 211 × 223 |
| 16:9 | 170" | 3763 × 2116 | 40 | 100 | 2425 | 3994 | 4084 × 211 × 223 |
| 16:9 | 180" | 3984 × 2241 | 40 | 100 | 2550 | 4215 | 4305 × 211 × 223 |
The recorded measurements are for general reference only. Please contact Carson Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification. Although a manufacturer may offer product advice, it may be taken or ignored at the integrator’s discretion. Carson Screens will not be held responsible or be otherwise liable for faulty installations.
