Description
Engineered for a Flawless Picture
More Screen. Less Frame.
On the other hand, bezel-free screens give you an ultra modern look and the largest screen that can possibly fit on your wall, but because the material has to wrap around to the back of the frame structure, tension is lost and the resulting image surface is significantly less flat, with crests and dips often showing up on the edges and even in the middle of the display area.
Carson’s revolutionary Zedge frame structure combines the best aspects of traditional and bezel-free designs to create a screen that, for the first time, delivers peak visual real estate and flatness simultaneously. By introducing advanced robotic Z-axis machining techniques, Carson engineers were able to move the side material tension points almost to the very edge of the frame bars. The result is a screen with just a 1.2cm bezel (almost zero in real-life appearance) while maintaining the highest surface tension possible for the ultimate, completely flat picture experience that exceeds the geometric uniformity of any glass fronted TV/monitor available on the market today.
Material
Daylight Material II ALR 8K
Carson’s Daylight II HDR 8K material incorporates next generation Z-axis lattice coating technology to achieve ultra fine-grained 8K+ resolving ability while absorbing 85% of ambient light from directions other than the projector so that you can enjoy full colour images even when the curtains are open/lights are on. The material has 0.8 gain and uniformly transmits vivid colour in a wide 160 degree arc for the entire audience to enjoy.
Made from a dark nano particle mix formed on top of a bulk polymer sublayer that prevents sunlight penetration from the rear, Daylight II fully supports HDR10+, Dolby Vision and Rec. 2100, making it an excellent future proof investment for your current and future projectors.
Carson’s unique chemically engineering ensures this stable material is resistant to creasing, UV, moisture, dust, fire, discolouration and ageing so your screen will continue to perform day-in, day-out for decades to come.
Blacker Blacks, Whiter Whites.
CARSON BLACK 85% light rejection vs MATT WHITE 15% light rejection
Measurements
| Format | Screen Size | Viewing Area (mm) | Installation Area (mm) |
|---|---|---|---|
| 16:9 | 80" | 1771 × 996 | 1795 × 1020 |
| 16:9 | 92" | 2036 × 1145 | 2061 × 1144 |
| 16:9 | 100" | 2213 × 1245 | 2237 × 1269 |
| 16:9 | 110" | 2435 × 1369 | 2459 × 1393 |
| 16:9 | 120" | 2656 × 1494 | 2680 × 1518 |
| 16:9 | 130" | 2877 × 1618 | 2902 × 1643 |
| 16:9 | 140" | 3099 × 1743 | 3123 × 1767 |
| 16:9 | 150" | 3320 × 1867 | 3344 × 1891 |
The recorded measurements are for general reference only. Please contact Carson Screens to verify product design and dimensions before attempting to integrate its products with any structural or furniture modification. Although a manufacturer may offer product advice, it may be taken or ignored at the integrator’s discretion. Carson Screens will not be responsible or otherwise liable for faulty installations.
